1. Introduction

FUOOTECH PL Series Portable Press Oil Filter Machine is also called Plate and frame filter press, Frame Filter, Plate Oil Filter, Oil Mill Filter Press, etc. FUOOTECH supplies various models of plate and frame filter presses in different sizes and varied capacities. Besides, we can also offer frame filter press according to customers' requirement. We are your trusted supplier in China.

PL Series Plate Frame Press Oil Purifier is used for filtration of micron sized solids in liquids. It has rationalization structure, convenient maintenance and is also very easy to operate, cleaning residual easier and faster. So it is well welcomed by all the users from every walk of life.

This Mini Oil Filter Press Machine is designed with a fine-mesh filtering cloth or filtering paper, making it particularly efficient in oil refinement. The filtrating cloth or paper between the filter plates forms many rooms. Under the action of high pressure, the oil goes through the filtrating cloth or paper and then be expelled from the oil outlet.

2. Application

1). Edible oils processing industry:

The PL Series plate flame filter is suitable for oil production, food processing and small scale oil processing plant or small refinery plant, etc. for separating solids from crude oil for manufacturing edible or cooking oil.

This is due to the fact that the solids in this type of food are largely organic and oxidized over time, deteriorating the quality of the product. In the food industry, it is very important to increase the quality, taste and shelf pattern of the product as well as the need to obtain clear product. The desired final product quality is achieved in a very short time by holding solids up to 0.5 ~ 1 microns with PL press oil filter machine.

With our portable Oil Filter Press Machine, you can easily clean the following edible oils:

Nigella Oil, Sunflower Oil, Safflower Oil, Canola Oil, Pumpkin Seed Oil, Melon Seed Oil, Palm Seed Oil, Cumin Seed Oil, Grape Seed Oil, Coconut Oil, Lauri Fructus Oil, Apricot Seed Oil, Sesame Seed Oil, Hazelnut Oil, Peanut Oil, Walnut Oil, Opium Oil, Flax Seed Oil, Almond Oil, Pistachio Oil, Jajoba Oil, Mustard Seed Oil, Nettle Seed Oil, Raspberry Oil, Pepper Seed Oil, Tomato Seed Oil, Rosehip Oil, Jatropha Oil Pumpkin Seed Oil, Cocoa Bean Oil, Soy Bean Oil, Bilberry Seed Oil, Pistachio Oil etc.

2). Industrial oils processing industry:

Series PL Plate Frame Pressurized Type Oil Purifier is specially designed for power station, electricity factory, power electrical substation of industrial and mining enterprise, lube oil depot, tractor station, petroleum, chemical engineering, metallurgy, national defense industry, etc, filtering water content and impurities of transformer oil, turbine oil, lube oil, EP gear oil, machine oil, diesel oil, hydraulic oil. It's a great choice as pre-treatment equipment prior to high vacuum oil purifier machines.

Series PL Plate Frame Pressurized Type Oil Purifier is mainly made up of machine base, filtering bed, boosting type oil pump, rough filter, tension bolt and filter plate. There are filtering medias, such as filtering paper or filtering cloth, installed between the steel filter board and filter plate that will be fixed to form a single filtering room under the pressure of the packing device. The filtering paper or filtering fuse packed between the filter board and filter plate will play a very important role of filtering.

3. Technical Parameters

Note: 1. The dimension and weight will be changed with changing of technical specs.

2. All the specs can be customized according to client's requirements.

4. Features

1). Plate pressure type filtering method, filter paper or filter cloth as filter media, simple operation.

2). No heating, the additives in the oil are well prevented from degradation or deterioration

3). Simple structure, small volume, light weight, easy to carry and operate

4). Low operation cost, Low maintenance time and cost

5). Special boosting type oil pump has strong suction ability and make the machine to be used in more oil types

6). Low noise, Quick and convenient to replace filter paper or filtering cloth.

7). Can effectively purify the tiny and fine mechanical impurity from oil.

5. Packing, Delivery, Shipping and Payment

6. Certificates

7. Eye Catching Points Of PL Filter Press

● We are pioneers in fabricated steel structure of filter press.

● We do supply base table or casters to give height to filter press. So no need to construct pillars by bricks & installation time and energy is saved considerably.

● Accurate machining of plates for leak proof joints to withstand operating pressure.

● Filter clothes or paper can be replaced easily.

● Screw thread is machined such that plates are separate with 50% effort compared to other filter presses.

● We sell specially designed unique filter pump. Some people insist to use only our filter pump only.

● Aesthetic color coating to filter press for better look.
