Cooking Oil/Palm Oil/Vegetable Oil Filtration Plant
Series COP Oil Filtration Plant is special for filtering waste cooking oil, dirty vegetable oil, palm oil, trench oil, swill oil, animal oil etc. It effectively removes particles, water, acid and other waste residues etc. from the waste oil.
According cooking oil nature, the used cooking oil contains high water, lots of impurities and carbons. This type machine dewaters, particles removal and eliminates impurities highly effectively.
This machine can be used as a pre-treatment process of producing biofuel & biodiesel, helping clients clean the used cooking oils by removing particles, water content, gas content, etc…
It's built with Heavy duty frame and solid rubber wheels which make moving easy.
|
Item |
Unit |
COP-10 |
COP-20 |
COP-30 |
COP-50 |
COP-100 |
COP-150 |
COP-200 |
COP-300 |
|
Flow rate |
L/H |
600 |
1200 |
1800 |
3000 |
6000 |
9000 |
12000 |
18000 |
|
Vacuum degree |
Mpa |
-0.06 ~ - 0.095 |
|||||||
|
Working pressure |
Mpa |
≤0.4 |
|||||||
|
|
℃ |
0 ~ 100 |
|||||||
|
Operation Temperature |
℃ |
50 ~ 70 |
|||||||
|
Demulsification |
Min |
New oil≤15min, running oil≤30min |
|||||||
|
Power supply |
|
380 VAC, 50 Hz, 3 Phase (or as per required) |
|||||||
|
Working noise |
DB (A) |
≤ 65 ~ 90 |
|||||||
|
Electric heating power |
KW |
30 |
36 |
48 |
60 |
72 |
90 |
120 |
135 |
|
Total electric power |
KW |
32.5 |
39 |
51 |
69 |
80 |
96 |
134 |
147 |
|
Inlet (outlet) caliber |
mm |
Ф25 |
Ф25 |
Ф25 |
Ф32 |
Ф42 |
Ф50 |
Ф50 |
Ф60 |
|
Dimension (L × W × H) |
mm |
1630 x1050 x 1730 |
1700 x1090 x1790 |
1780 x1150 x1850 |
1800 x 1200 x1900 |
1930 x1450 x 1960 |
1940 x1600 x2060 |
1980 x1700 x2100 |
2100 x1760 x2200 |
|
Weight |
Kg |
580 |
660 |
700 |
750 |
850 |
1000 |
1200 |
1500 |
It Purifies&Features:
Vegetable Oil /Sunflower oil /Palm Oil /Cooking Oil/ Industrial lube oil
①Multi-stage heating
②Vacuum dehydration & dewatering
③Degassing
④As pre-treatment process for producing biodiesel ⑤Multi-stage filtration effective particles removal
⑥Oil filling & transferring
⑦Filter press device installed
