Chongqing Fuootech Oil Purifier Technologies Co., Ltd. is one of the most reliable manufacturers and suppliers of 1200 LPM High Velocity Oil Flushing System in China, also supports customized service with low price. Welcome to wholesale CE approved 1200 LPM High Velocity Oil Flushing System made in China here from our factory. Also, one year warranty is available.
High Velocity Oil Flushing System is specially designed for flushing and cleaning the oil system of large-scale equipment. It is used to completely and quickly remove particles, debris, sludge and moisture inside the oil system to ensure safe production and reliable operation of the equipment.
High Velocity Oil Flushing System is fully integrated and specially developed for flushing the oil system of large equipment, which is developed by absorbing and developing the advanced rapid flushing technology from USA. While flushing is proceeded, it can also filter the oil by removing various impurities, particles, fiber, sludge, moisture, etc.
High efficiency, low operation cost, simple operation and maintenance, and reliable operation.
Technical Parameter
|
Parameter |
FT-FL-600 |
FT-FL-1200 |
FT-FL-2000 |
FT-FL-4000 |
FT-FL-5500 |
|
Flushing rate (L/min) |
600 |
1200 |
2000 |
4000 |
5500 |
|
Applications |
Lube & Hydraulic pipeline system |
||||
|
Filter Stage |
3 |
3 |
3 |
3 |
3 |
|
Power Supply |
380 V, 50 Hz, 3 phase |
||||
|
Average trouble-free Working Time |
≥ 5000H |
||||
|
Size (mm) |
2000×1500×1750 |
3200×2000×2020 |
3600×2100×2100 |
4000×2100×2050 |
4800×2200×2150 |
|
Approx. Weight (KGS) |
1600 |
2500 |
3800 |
4500 |
6200 |
|
Note: The dimension and weight will be changed with changing of technical specs. All the specs can be customized according to client's requirements. |
|||||
Features:
1). Durable Oil Pump installed, ensuring the high performance in various applications;
2). Has fast oil delivery and filtration functions, it can transfer the oil between the oil tank and the oil drum;
3). The three functions of flushing only, flushing + fine filtration, flushing + fine filtration + high-precision filtration can be freely selected according to the oil system flushing requirements;
4). Heavy duty oil heater system and stainless steel oil tank are equipped;
5). Flow meter installed for monitoring the oil flow rate in time;
6). PLC + HMI installed for more convenient operation, high automation;
Certificates
